The Femoral Head of Patients with Hip Dysplasia is not as Osteogenic as Iliac Crest Bone Location

Main Article Content

Yasuhiro Homma
Arnaud Dubory
Jacques Paria
Damien Potage
Charles Henri Flouzat Lachaniette
Nathalie Chevallier
Helene Rouard
Philippe Hernigou*

Abstract

When Total Hip Arthroplasty (THA) is required in a patient with developmental dysplasia of the hip (DDH), bone deficiency in the acetabular roof often remains a problem. The iliac crest (IC) has long been the preferred source of autograft material, but graft harvest is associated with frequent complications and pain. Autologous bone graft can also be obtained from the femoral head (FH) for reconstruction of the acetabulum in hip arthroplasty. However, in certain challenging clinical scenarios, incorporation of the femoral head autograft appears less successful than the iliac crest autograft. The difference in potential for proliferation and osteoblastic differentiation between the two sites has still not been evaluated; therefore, it is not known how to compensate for this difference when it is present. We designed this study to evaluate the number of mesenchymal stem cells (MSCs) in both the iliac crest and femoral head of the same patient. We also determined the best operating room procedure for loading the femoral head with MSCs to achieve equivalent numbers of MSCs as in the IC. Twenty patients (8 men and 16 women) undergoing THA for DDH were enrolled in the study. The mean age was 55.5 years (range 41–65 years). Bone marrow aspirates were obtained from three depths within the femoral head and the aspirates were quantified relative to matched iliac crest aspirates that were obtained from the same patient at the same time. The cell count, progenitor cell concentration (cells/mL marrow), and progenitor cell prevalence (progenitor cells/million nucleated cells) were calculated.


Aspirates of FH marrow demonstrated less concentrations of mononuclear cells compared with matched controls from the iliac crest. Progenitor cell concentrations were consistently lower in FH aspirates compared to matched controls from the iliac crest (p = 0.05). The concentration of osteogenic progenitor cells was, on average, 40% lower in the FH aspirates than in the paired iliac crest samples (p = 0.05). However, with bone marrow aspirated from the iliac crest, we were able to load the femoral head autograft with sufficient MSCs to obtain the same number as present in an iliac crest. With concentrated bone marrow from the IC, supercharging the femoral autograft with MSCs to numbers above that present in the IC was possible in the operating room, and the number of MSCs supercharged in the femoral head was predictable.


Based on these findings we suggest that FH graft supercharged with BM-MSCs from the IC is comparable to IC graft for osseous graft supplementation especially in THA for patients with DDH.

Article Details

Homma, Y., Dubory, A., Paria, J., Potage, D., Lachaniette, C. H. F., Chevallier, N., … Hernigou, P. (2017). The Femoral Head of Patients with Hip Dysplasia is not as Osteogenic as Iliac Crest Bone Location. Journal of Stem Cell Therapy and Transplantation, 1(1), 001–007. https://doi.org/10.29328/journal.jsctt.1001001
Research Articles

Copyright (c) 2017 Homma Y, et al.

Creative Commons License

This work is licensed under a Creative Commons Attribution 4.0 International License.

The Journal of Stem Cell Therapy and Transplantation is committed in making it easier for people to share and build upon the work of others while maintaining consistency with the rules of copyright. In order to use the Open Access paradigm to the maximum extent in true terms as free of charge online access along with usage right, we grant usage rights through the use of specific Creative Commons license.

License: Copyright © 2017 - 2025 | Creative Commons License Open Access by Journal of Stem Cell Therapy and Transplantation is licensed under a Creative Commons Attribution 4.0 International License. Based on a work at Heighten Science Publications Inc.

With this license, the authors are allowed that after publishing with the journal, they can share their research by posting a free draft copy of their article to any repository or website.

Compliance 'CC BY' license helps in:

Permission to read and download
Permission to display in a repository
Permission to translate
Commercial uses of manuscript

'CC' stands for Creative Commons license. 'BY' symbolizes that users have provided attribution to the creator that the published manuscripts can be used or shared. This license allows for redistribution, commercial and non-commercial, as long as it is passed along unchanged and in whole, with credit to the author.

Please take in notification that Creative Commons user licenses are non-revocable. We recommend authors to check if their funding body requires a specific license.

Baba T, Shitoto K. Revision of total hip arthroplasty using the Kerboull and KT plates. Int Orthop. 2010; 34: 341-347. Ref.: https://goo.gl/qzNMKh

Charnley J, Feagin JA. Low-friction arthroplasty in congenital subluxation of the hip. Clin Orthop Relat Res. 1973; 91: 98-113. Ref.: https://goo.gl/DxR1sN

Delimar D, Bohacek I, Pecina M, Bicanic G. Acetabular roof reconstruction with pedicled iliac graft: ten years later. Int Orthop. 2014; 38: 199-201. Ref.: https://goo.gl/zs3gp8

Fujiwara M, Nishimatsu H, Sano A, Misaki T. Acetabular roof reconstruction using a free vascularized fibular graft. J Reconstr Microsurg. 2006; 22: 349-352. Ref.: https://goo.gl/yzw0dU

Gerber SD, Harris TW. Femoral head autografting to augment acetabular deficiency in patients requiring total hip replacement: a minimum five-year and an average seven-year follow-up study. J Bone Joint Surg Am. 1986; 68: 1241-1248. Ref.: https://goo.gl/4qblF5

Caplan AI. Why are MSCs therapeutic? New data: new insight. J Pathol. 2009; 217: 318-324. Ref.: https://goo.gl/s4vtrO

Friedenstein AJ, Petrakova KV, Kurolesova AI, Frolova GP. Heterotopic of bone marrow. Analysis of precursor cells for osteogenic and hematopoietic tissues. Transplantation. 1968; 6: 230-247. Ref.: https://goo.gl/k0buBQ

Hernigou P, Poignard A, Beaujean F, Rouard H. Percutaneous autologous bone-marrow grafting for nonunions. Influence of the number and concentration of progenitor cells. J Bone Joint Surg Am. 2005; 87: 1430-1437. Ref.: https://goo.gl/GpMqly

Hernigou P, Homma Y, Flouzat Lachaniette CH, Poignard A, Allain J, et al. Benefits of small volume and small syringe for bone marrow aspirations of mesenchymal stem cells. Int Orthop. 2013; 37: 2279-2287. Ref.: https://goo.gl/ddCAz4

Chevallier N, Anagnostou F, Zilber S, Bodivit G, Maurin S, et al. Osteoblastic differentiation of human mesenchymal stem cells with platelet lysate. Biomaterials. 2010; 31: 270-278. Ref.: https://goo.gl/zaJpNx

Hernigou P, Pariat J, Queinnec S, Homma Y, Flouzat Lachaniette CH, et al. Supercharging irradiated allografts with mesenchymal stem cells improves acetabular bone grafting in revision arthroplasty. Int Orthop. 2014; 38: 1913-1921. Ref.: https://goo.gl/Gw5wnJ

Homma Y, Kaneko K, Hernigou P. Supercharging allografts with mesenchymal stem cells in the operating room during hip revision. Int Orthop. 2014; 38: 2033-2044. Ref.: https://goo.gl/h1zxlJ

Gross AE, Catre MG. The use of femoral head autograft shelf reconstruction and cemented acetabular components in the dysplastic hip. Clin Orthop Relat Res. 1994; 298: 60-66. Ref.: https://goo.gl/LUAmoQ

Hartofilakidis G, Karachalios T. Total hip arthroplasty for congenital hip disease. J Bone Joint Surg Am. 2004; 86-A: 242-250. Ref.: https://goo.gl/g6ZHU7

Hintermann B, Morscher EW. Total hip replacement with solid autologous femoral head graft for hip dysplasia. Arch Orthop Trauma Surg. 1995; 114: 137-144. Ref.: https://goo.gl/H10X5k

Iida H, Matsusue Y, Kawanabe K,Okumura H, Yamamuro T, et al. Cemented total hip arthroplasty with acetabular bone graft for developmental dysplasia. Long-term results and survivorship analysis. J Bone Joint Surg Br. 2000; 82: 176-184. Ref.: https://goo.gl/4D7Y3X

Mulroy RD, Harris WH. Failure of acetabular autogenousngrafts in total hip arthroplasty. Increasing incidence: a follow-up note. J Bone Joint Surg Am. 1990; 72: 1536-1540. Ref.: https://goo.gl/sbesuJ

Inao S, Gotoh E, Ando M. Total hip replacement using femoral neck bone to graft the dysplastic acetabulum: follow-up study of 18 patients with old congenital dislocation of the hip. J Bone Joint Surg Br. 1994; 76: 735-739. Ref.: https://goo.gl/9Bzt3B

Hernigou P, Dubory A, Roubineau F, Homma Y, Flouzat-Lachaniette CH, et al. Allografts supercharged with bone-marrow-derived mesenchymal stem cells possess equivalent osteogenic capacity to that of autograft: a study with long-term follow-ups of human biopsies. Int Orthop. 2016; DOI 10.1007/s00264-016-3263-7. Ref.: https://goo.gl/9y3nq7

Inao S, Matsuno T. Cemented total hip arthroplasty with autogenous acetabular bone grafting for hips with developmental dysplasia in adults: the results at a minimum of ten years. J Bone Joint Surg Br. 2000; 82: 375-377. Ref.: https://goo.gl/CEFUbb

Kim M, Kadowaki T. High long-term survival of bulk femoral head autograft for acetabular reconstruction in cementless THA for developmental hip dysplasia. Clin Orthop Relat Res. 2010; 468: 1611-1620. Ref.: https://goo.gl/WtTmbr

Kobayashi S, Saito N, Nawata M, Horiuchi H, Iorio R, et al. Total hip arthroplasty with bulk femoral head autograft for acetabular reconstruction in developmental dysplasia of the hip. J Bone Joint Surg Am. 2003; 85-A: 615-621. Ref.: https://goo.gl/esB22K

Schreurs BW, Busch VJ, Welten ML, et al. Acetabular reconstruction with impaction bone-grafting and a cemented cup in patients younger than fifty years old. J Bone Joint Surg [Am]. 2004; 86-A: 2385-2392. Ref.: https://goo.gl/m4kpgh

Van Haaren EH, Heyligers IC, Alexander FG, Wuisman PI. High rate of failure of impaction grafting in large acetabular defects. J Bone Joint Surg Br. 2007; 89: 296-300. Ref.: https://goo.gl/w0P5Pb

Coquelin L, Fialaire-Legendre A, Roux S, Poignard A, Bierling P, et al. In vivo and in vitro comparison of three different allografts vitalized with human mesenchymal stromal cells. Tissue Eng Part A. 2012; 18: 1921-1931. Ref.: https://goo.gl/XYHiq7

Deakin DE, Bannister GC. Graft incorporation after acetabular and femoral impaction grafting with washed irradiated allograft and autologous marrow. J Arthroplasty. 2007; 22: 89-94. Ref.: https://goo.gl/0NcnLe

Hisatome T, Yasunaga Y, Yanada S, Tabata Y, Ikada Y, et al. Neovascularization and bone regeneration by implantation of autologous bone marrow mononuclear cells. Biomaterials. 2005; 26: 4550-4556. Ref.: https://goo.gl/td21Wl

Kruyt MC, de Bruijn JD, Yuan H, van Blitterswijk CA, Verbout AJ, et al. Optimization of bone tissue engineering in goats: a preoperative seeding method using cryopreserved cells and localized bone formation in calcium phosphate scaffolds. Transplantation. 2004; 77: 359-365. Ref.: https://goo.gl/JmD8fI

Kon E, Muraglia A, Corsi A, Bianco P, Marcacci M, et al. Autologous bone marrow stromal cells loaded onto porous hydroxyapatite ceramic accelerate bone repair in critical-size defects of sheep long bones. J Biomed Mater Res. 2000; 49: 328-337. Ref.: https://goo.gl/ptf3uF

Léotot J, Lebouvier A, Hernigou P, Bierling P, Rouard H, et al. Bone-Forming Capacity and Biodistribution of Bone Marrow-Derived Stromal Cells Directly Loaded Into Scaffolds: A Novel and Easy Approach for Clinical Application of Bone Regeneration. Cell Transplant. 2015; 24: 1945-1955. Ref.: https://goo.gl/VmHJ2o
